Fronius Wattpilot – technical data Go 22 J 2.0 AUS
Residual current device
20 mA
AC
, 6 mA
DC
Supply line cable cross-section
Min. 6 mm
2
RFID (radio frequency identification)
13.56 MHz
WLAN
IEEE 802.11b/g/n | 2.4 GHz
Supported safety standards
WEP, WPA, WPA2, WPA3
Safety class
IP 55
Impact resistance
IK08
Dimensions (width x height x depth)
155 x 287 x 109 mm
Weight
2 kg
Use
Indoors and outdoors
No direct sunlight
Installation type
Suspended
Ambient temperature
-25 to +40 °C
Average ambient temperature over 24
hours
Max. 35 °C
Humidity
5 - 95%
Height above sea level
0 - 2,000 m
Wattpi-
lot Home 11 J 2.0
Fronius Wattpilot – technical data Home 11 J 2.0
Max. charging power 11 kW
Mains supply types TT / TN / IT
Mains connection 5‑pin cable
Nominal voltage 230 and 240 V (1‑phase) / 400 and
415 V (3‑phase)
Mains current (configurable) 6 ‑ 16 A
1‑phase or
3‑phase
Grid frequency 50 Hz
Power consumption in standby 1.9 W (LED dark), 4.2 W (LED bright)
Charging socket Type 2 infrastructure socket with
mechanical lock
Residual current device 20 mA
AC
, 6 mA
DC
Supply line cable cross-section
Min. 6 mm
2
RFID (radio frequency identification) 13.56 MHz
WLAN IEEE 802.11b/g/n | 2.4 GHz
Supported safety standards WEP, WPA, WPA2, WPA3
Safety class IP 55
Impact resistance IK08
Dimensions (width x height x depth) 155 x 287 x 109 mm
65
EN
