2 Product Overview
42
Product Overview
2
Note • In this guide, the duplex automatic document feeder (optional) is referred to as the
“document feeder” or “DADF”.
Telephone line connectors
Note • The Fax service is not available for some models. An optional component is required. For
more information, contact our Customer Support Center.
• LINE 2 (Line 2) and LINE 3 (Line 3) are optional.
• When you talk into the external telephone receiver connected to TEL, only the line
connected to LINE 1 is available. (LINE 2 and LINE 3 are not available.)
No.
Name marked on
the cover of the
machine
Name displayed on
the touch screen
Function
1 TEL - Enables you to connect the machine to a telephone
device.
2 LINE 1 Line 1 Use this connector to connect to a telephone line.
3 LINE 2 Line 2 Use this connector to connect to a telephone line.
4 LINE 3 Line 3 Use this connector to connect to a telephone line.
TEL LINE1
LINE2
LINE3
12
3
4
To Next Page
