Machine Components
45
Product Overview
2
Note • The Finisher-B1 is optional. In this guide, the Finisher-A1 and Finisher-B1 are referred to as
the "finisher".
• The power cord connected to the Finisher-B1 is a connecting cord dedicated to the machine.
Do not connect this cord to any other devices than the machine.
13 US 2/3 Hole Punch Kit (US
standard) (optional)
2/4 Hole Punch Kit
(optional)
Hole-punches outputs.
Note • The distance between the two holes made with the US 2/3 Hole
Punch Kit (US standard) is 70 mm, which is different from the 80
mm distance made with the 2/4 Hole Punch Kit.
14 Center tray (Top transport
cover)
Copies and prints are delivered here when they are unable to be
delivered to the output tray or the finisher tray.
Pull the cover upward when clearing paper jams.
Note • Remove outputs delivered to the center tray constantly.
No. Component Function
To Next Page
