Paper Jams
281
Problem Solving
13
2) If the paper is jammed in the location as
shown in the right figure, remove the jammed
paper pulling upwards.
3) Push on the center of the left cover, close it
slowly, and raise the Tray 5 (bypass).
Paper Jam in One Tray Module Cover [B]
Follow the steps below to clear paper jams inside the machine's one tray module cover.
1 Pull the release lever, and slowly open the one
tray module cover.
2 Remove the jammed paper.
Note • The paper may be jammed in the upper part
where it is difficult to see. Check thoroughly for
jammed paper.
• If the paper tears, check to make sure there are
no remaining shreds in the machine.
3 Close the one tray module cover gently.
To Next Page
