15 Problem Solving
628
Problem Solving
15
Staple Jams in Staple Cartridge (for C3 Finisher and C3 Finisher with Booklet
Maker)
This section describes how to clear staple jam occurred in the staple cartridge of the C3
Finisher (optional) and the C3 Finisher with Booklet Maker (optional).
1 Make sure that the machine has stopped, and
open the finisher front door.
2 With grasping the lever [R1] of the staple
cartridge holder, pull the staple cartridge holder
to the right, towards you.
3 With grasping the orange lever, pull out the
staple cartridge.
Note • The staple cartridge is firmly inserted. A slight
force is required to pull the cartridge out of
the finisher.
• When the C3 Finisher Staple Unit 65 Sheets
(optional) is installed, pull down the orange
lever, and pull out the staple cartridge.
4 After removing the staple cartridge, check the
inside of the finisher for any remaining staples.
To Next Page
