Printing Basics 81
2
Slide the width guides to the edge of the tray. The width guides should be fully extended.
3
Insert all media face up and top edge first into the bypass tray.
NOTE:
• Do not force the print media into the bypass tray.
4
Slide both width guides until they rest lightly against the edge of the print media stack.
NOTE:
• Do not force the print media into the bypass tray.
5
On the operator panel, select the appropriate paper size, and then press the button.
NOTE:
• If you use the driver setting, select Use Driver Settings.
6
Select the appropriate paper type, and then press the button.
Loading Small Print Media in the Bypass Tray
When loading small print media such as monarch envelope or the user-specified print media whose feed direction length is
191.6 mm or less in the bypass tray, remove the bypass tray from the printer.
1
Gently pull open the bypass tray cover.
To Next Page
