Operation
20 A26361-K675-Z120-1-7619, edition 3
Indicators on the PC
The indicators are on the front of the PC. Which indicators are available on your PC depends on the
configuration level you have selected.
1
2
4
3
5
1 = CD-ROM indicator
2 = Floppy disk indicator
3 = SmartCard reader indicator
4 = Power-on indicator
5 = Hard disk indicator
1 - CD-ROM indicator
The indicator lights up when the CD-ROM drive is accessed. You may only remove the CD when the
indicator is dark.
2 - Floppy disk indicator
The indicator lights up when the floppy disk drive of the PC is accessed. You may only remove the
floppy disk when the indicator is unlit.
3 - SmartCard reader indicator
The indicator lights up when the SmartCard reader is ready-to-use.
The indicator flashes when the SmartCard is accessed.
