System expansions
44 A26361-K675-Z120-1-7619, edition 3
Replacing drive in 5 ¼ inch bay
► Open the casing (see "Opening the casing" chapter).
Removing a drive
► Pull the data and the power supply connectors from the desired drive.
► Press the EasyChange rails (1) together and pull the drive out of the casing (2).
► Remove the EasyChange rails from the drive.
i
If your PC is equipped with a drive carrier instead of the drive, you can remove and install
the carrier in the same way.
