A26361-K675-Z120-1-7619, edition 3 63
Technical data
Electrical data
Regulations complied with:
IEC60950/EN60950, UL60950,
CSA22.2 No.60950
Protection class:
I
Rated voltage range:
100 V -240 V
Frequency:
50 Hz - 60 Hz
Max. rated current
● PC with monitor socket:
100 V - 127 V
200 V -240 V
6.0 A
3.0 A
● Monitor socket (output):
100 V - 127 V
200 V -240 V
3.0 A
1.5 A
Dimensions
Width/depth/height:
350 mm/383 mm/95 mm
Weight
with the basic configuration
approx. 9.7 kg
Environmental conditions
Environment class (3K2)
Environment class (2K2)
DIN IEC 721 part 3-3
DIN IEC 721 part 3-2
Temperature:
● Operating (3K2)
● Transport (2K2)
15 °C .... 35 °C
-25 °C .... 60 °C
Condensation in operating must be avoided.
Clearance required to ensure adequate ventilation
Horizontal operating position:
● front
● rear
● right-hand side
min. 200 mm
min. 200 mm
min. 200 mm
Vertical operating position:
● front
● rear
● top
min. 200 mm
min. 200 mm
min. 200 mm
i
The data sheet of the PC contains further technical data. You will find the data sheet on
the internet at http://www.fujitsu-siemens.com/
