Fujitsu Siemens Computers SCENIC E - Replacing Second Hard Disk in 5 ¼ Inch Drive Carrier

System expansions
A26361-K675-Z120-1-7619, edition 3 51
► Fold down the drive cage (see chapter "Folding up and down the drive cage").
► Close the casing (see "Closing the casing" chapter).
i
It may be necessary to modify the entry for the drive in the BIOS Setup.
Replacing second hard disk in 5 ¼ inch drive carrier
► Remove the drive carrier as described in "Replacing drive in 5 ¼ inch bay" chapter.
Removing the hard disk
2
1
1
1
1
► Remove the screws (1).
► Pull the hard disk out of the drive carrier in the direction of the arrow (2).
