System expansions
36 A26361-K675-Z120-1-7619, edition 3
► Push the board up to its slot in the
direction of the arrow as far as the stop.
► Press the board into the slot so that it
engages.
► Fold up the retaining bracket so that it
engages.
► If necessary, connect the cables.
► Reinstall the board bracket in reverse
order as described above.
► Close the casing (see "Closing the
casing").
i
If you have installed or removed a PCI board, check the relevant PCI slot settings in the
BIOS Setup. If necessary, change the settings. Further information is provided in the PCI
board documentation.
The upper slot is suitable for low-profile cards with an adapter.
