System expansions
38 A26361-K675-Z120-1-7619, edition 3
► Push the slot cover into the slot in the
direction of the arrow. Ensure that the
point of the slot cover engages on the
outside of the board bracket.
► Fold up the retaining bracket so that it
engages.
!
For cooling, protection against fire, and in order to comply with EMC (electromagnetic
compatibility) regulations, you must refit the slot cover.
i
If you have installed or removed a PCI board, please check the relevant PCI slot settings
in the BIOS Setup. If necessary, change the settings. Further information is provided in the
PCI board documentation.
The upper slot is suitable for low-profile cards with an adapter.
