Mounting
RU can be installed on a wall or pole away from the antenna. Heat generated by the RU can be radiated to the
antenna through the mounting bracket. Mounting details, for example, conguration and position of the
mounting bracket, are determined aer consultation with the antenna vendor.
Mounting an RU has the following requirements.
■ Mounting the RU requires a pole to be within 2 to 4.5 inches in diameter.
■ e wall mounting surface and anchors must be able to withstand up to 240 lbs (108.862 kg) of weight.
e following graphic shows an RU aached to a pole with a pole mounting kit.
Figure 9
Pole Mount Final Result
Installation
Mounting
86
Release 1.0 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
