MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
3) Outlet directions
Select the appropriate number of outlet directions according to the installation conditions.
(

... Factory setting)
Function number Setting value Setting description
22
00 4-way

01 3-way
4) Vertical airow direction range control
In a concealed installation, change the setting to "Fixed" (02) to restrict the movement of the
upper air outlet so that the airow is only towards the horizontal direction.
(

... Factory setting)
Function number Setting value Setting description
23
00 Standard

01 (Setting prohibited)
02 Fixed (Concealed)
5) Static pressure
Select the appropriate static pressure according to the installation conditions.
(

... Factory setting)
Function number Setting value Setting description
26
00 0 Pa
01 10 Pa
02 20 Pa
03 30 Pa
04 40 Pa
05 50 Pa
06 60 Pa
07 70 Pa
08 80 Pa
09 90 Pa
31 25 Pa [Standard]

6) Room temperature sensor control for cooling
Depending on the installed environment, correction of the room temperature sensor may be
required.
Select the appropriate control setting according to the installed environment.
(

... Factory setting)
Function number Setting value Setting description
30
00 Standard

01 Slightly lower control
02 Lower control
03 Higher control
In case of Slim duct type and Floor/Ceiling type models: In oor console installations, select
"01".
7) Room temperature sensor control for heating
Depending on the installed environment, correction of the room temperature sensor may be
required.
Select the appropriate control setting according to the installed environment.
(

... Factory setting)
Function number Setting value Setting description
31
00 Standard

01 Lower control
02 Slightly higher control
03 Higher control
In case of Slim duct type and Floor/Ceiling type models: In oor console installations, select
"01".
