MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
FUNCTIONS [Wall mounted (LM) type]

Display panel
2
3
6
1
18
9
15
12
13
11
10
14
16
17
4
8
7
5
19
20
22
23
24
25
21
To facilitate explanation, the accompanying
illustration has been drawn to show all
possible indicators; in actual operation,
however, the indicator will only show
those indicators appropriate to the current
operation.
①
Signal Transmitter
②
10 °C HEAT button
③
MODE button
④
ECONOMY button
⑤
OUTDOOR UNIT LOW NOISE button
⑥
ON TIMER button
⑦
OFF TIMER button
⑧
CLOCK ADJUST button
⑨
POWERFUL button
⑩
TEMP. Set button ( / )
⑪
Start/Stop button
⑫
FAN button
⑬
SWING button
⑭
SET button
⑮
SLEEP TIMER button
⑯
CANCEL button
⑰
RESET button
⑱
TIMER SELECT button ( / )
⑲
Remote Controller Display
⑳
Operation Mode Indicator
㉑
Low Noise Mode Indicator
㉒
Temperature Set Indicator
㉓
Fan Speed Indicator
㉔
Swing Indicator
㉕
Clock & Timer Indicator
NOTE: Functions will be different due to type of indoor unit.
For details, please see operation manual.
