Front View
Top View
Side View
[Unit : mm]
Holder
z
Front View Side View Bottom View
Control signal may not be recognized in following cases: ●
(i) A curtain or a wall, etc. exists between transmitter and receiver.
(ii) There is an instant-start type (inverter type, etc.) uorescent
lampin the room.
Air conditioner may not work correctly when strong light hits the signal ●
receiver window. Shut off direct sunlight and also place illuminator far
away from the receiver window.
Signal transmitter
Signal receiver
window
To Next Page
