Fujitsu AO*G24LAT3 User Manual

- (03 - 41) -
OUTDOOR UNIT AO

G18-24L3
OUTDOOR UNIT AO

G18-24L3
INDOOR UNIT : 12000Btu (AO
 
G18L3, AO

G24L3)
H
H
Height difference H

1 Indoor unit is higher than outdoor unit.

2 Indoor unit is lower than outdoor unit.
Indoor unit
Indoor unit
Connection pipe
Outdoor unit
Outdoor unit
Connection pipe
HEATING
Pipe length (m)
5 7. 5 10 15 20 25
Height
difference H
(m)

1
Indoor unit is
higher than
outdoor unit.
15 - - - 0.975 0.957 0.940
10 - - 0.990 0.975 0.957 0.940
7.5 - 1.000 0.990 0.975 0.957 0.940
5 1.000 1.000 0.990 0.975 0.957 0.940
0 1.000 1.000 0.990 0.975 0.957 0.940

2
Indoor unit
is lower than
outdoor unit
-5 0.995 0.995 0.985 0.970 0.952 0.936
-7. 5 - 0.993 0.983 0.968 0.950 0.934
-10 - - 0.980 0.965 0.947 0.931
-15 - - - 0.960 0.943 0.926
COOLING
Pipe length (m)
5 7. 5 10 15 20 25
Height
difference H
(m)

1
Indoor unit is
higher than
outdoor unit.
15 - - - 0.933 0.899 0.859
10 - - 0.970 0.940 0.906 0.866
7.5 - 0.988 0.974 0.944 0.910 0.869
5 0.992 0.992 0.978 0.948 0.913 0.873
0 1.000 1.000 0.986 0.956 0.921 0.880

2
Indoor unit
is lower than
outdoor unit
-5 1.000 1.000 0.986 0.956 0.921 0.880
-7. 5 - 1.000 0.986 0.956 0.921 0.880
-10 - - 0.986 0.956 0.921 0.880
-15 - - - 0.956 0.921 0.880
