- (04 - 59) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
Indoor unit : 7000Btu + 9000Btu + 12000Btu + 18000Btu
z
Indoor unit : 7000Btu + 9000Btu + 14000Btu + 14000Btu
z
Indoor unit : 7000Btu + 9000Btu + 14000Btu + 18000Btu
z
Indoor unit : 7000Btu + 12000Btu + 12000Btu + 12000Btu
z
TC : Total Capacity (kW)
IP : Input Power (kW)
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+9+12+18
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 8.06 3 .13 7.87 3.19 7.68 3.26 7.49 3.32 7.30 3.39
-5 -7 9.07 3.26 8.86 3.33 8.64 3.40 8.42 3.47 8.21 3.54
0 -2 10.46 3.44 10.21 3.51 9.96 3.58 9.71 3.58 9.46 3.58
5 3 11.78 3.44 11.50 3.51 11.22 3.58 10.94 3.58 10.66 3.58
7 6 12.60 3.44 12.30 3.51 12.00 3.58 11.70 3.58 11.40 3.58
10 8 13.10 3.44 12.79 3.51 12.48 3.58 12.17 3.58 11.86 3.58
15 10 13.04 3.20 12.73 3.26 12.42 3.33 12.11 3.34 11.80 3.34
20 15 11.09 2.21 10.82 2.30 10.56 2.30 10.30 2.30 10.03 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+9+14+14
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 7.93 3.13 7.74 3.19 7.55 3.26 7.36 3.32 7.17 3.39
-5 -7 8.92 3.26 8.71 3.33 8.50 3.40 8.28 3.47 8.07 3.54
0 -2 10.28 3.44 10.04 3.51 9.79 3.58 9.55 3.58 9.30 3.58
5 3 11.58 3.44 11.31 3.51 11.03 3.58 10.76 3.58 10.48 3.58
7 6 12.39 3.44 12.10 3.51 11.80 3.58 11.51 3.58 11.21 3.58
10 8 12.89 3.44 12.58 3.51 12.27 3.58 11.97 3.58 11.66 3.58
15 10 12.82 3.20 12.52 3.26 12.21 3.33 11.91 3.34 11.60 3.34
20 15 10.90 2.21 10.64 2.30 10.38 2.30 10.12 2.30 9.86 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+9+14+18
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 8.06 3 .13 7.87 3.19 7.68 3.26 7.49 3.32 7.30 3.39
-5 -7 9.07 3.26 8.86 3.33 8.64 3.40 8.42 3.47 8.21 3.54
0 -2 10.46 3.44 10.21 3.51 9.96 3.58 9.71 3.58 9.46 3.58
5 3 11.78 3.44 11.50 3.51 11.22 3.58 10.94 3.58 10.66 3.58
7 6 12.60 3.44 12.30 3.51 12.00 3.58 11.70 3.58 11.40 3.58
10 8 13.10 3.44 12.79 3.51 12.48 3.58 12.17 3.58 11.86 3.58
15 10 13.04 3.20 12.73 3.26 12.42 3.33 12.11 3.34 11.80 3.34
20 15 11.09 2.21 10.82 2.30 10.56 2.30 10.30 2.30 10.03 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+12+12+12
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 7.73 3.13 7.54 3.19 7.36 3.26 7.18 3.32 6.99 3.39
-5 -7 8.69 3.26 8.49 3.33 8.28 3.40 8.07 3.47 7.87 3.54
0 -2 10.02 3.44 9.78 3.51 9.55 3.58 9.31 3.58 9.07 3.58
5 3 11.29 3.44 11.02 3.51 10.75 3.58 10.48 3.58 10.21 3.58
7 6 12.08 3.44 11.79 3.51 11.50 3.58 11.21 3.58 10.93 3.58
10 8 12.56 3.44 12.26 3.51 11.96 3.58 11.66 3.58 11.36 3.58
15 10 12.50 3.20 12.20 3.26 11.90 3.33 11.60 3.34 11.31 3.34
20 15 10.63 2.21 10.37 2.30 10.12 2.30 9.87 2.30 9.61 2.30
