Fujitsu AO*G24LAT3 User Manual

- (01-33) -
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
SYSTEM DIAGRAM

1 remote controller
z
z
2 remote controllers
Primary
Secon-
dary
A B C
Indoor unit Indoor unit
Remote controller Remote controllers
A , B , C : Remote controller cable.
ELECTRICAL WIRING

1 remote controller
z
z
2 remote controllers
Indoor unit
REMOTE
CONTROLLER
1 2 3
1 2 3
Primary
Secondary
Indoor unit
1 2 3
1 2 3 1 2 3
REMOTE
CONTROLLER
Remote controller Remote controllers
1 (RED) : 12V
2 (WHITE) : Signal
3 (BLACK) : COM
CONTROLLER COMBINATION

As for the combined usage of remote controllers, refer to following gures.
Good
z
UTY-RVNM UTY-RNNM UTY-RVNM UTY-RSNMUTY-RVNM UTY-RVNM
SET TEMP.
START/STOP
Indoor unit Indoor unit Indoor unit
