FUJITSU DL3100
User’s Manual D-11
Ethernet TCP/IP
When using your printer in a local network with Ethernet
connections and the TCP/IP protocol, you have to assign
address information.
Address information for the Ethernet Port can only be
made available by your network administrator, who has
the necessary rights to install Printers on the network
and/or make any changes.
If you want to set the Ethernet port, you need to use USB
to connect the DLMENU.
The use of Ethernet interface
1. Install Ethernet interface board into the printer. Connect
PC and the printer using the network cable. Turn on the
printer to connect DLMENU. The user interface is shown
as below.
2. Click “Ethernet” in step 1 to display the parameter setup
for Ethernet as below.
Printer IP address can be changed
when needed.
To Next Page
