Fujitsu DL3100 User Manual

FUJITSU DL3100
User’s Manual 1-7
Component Function
Gap Lever
Adjusts the print gap lever according to the
thickness of paper
Paper Guides
Adjusts positioning of single sheet paper
Sub Guide
Pull the sub-guide out as required to the
paper size
Sheet Feeder
Place the single paper, in order to load and
eject.
Print Head
24-pin printing mechanism
Cover
When printer is in operation, ensure the
printer’s cover is closed to keep the noise
level to a minimum, to ensure the user
security when the printer is operated.
Tear-off Edge
Help to tear off printed pages without
wasting paper.
Control Panel
Shows printer status, for printer setup,
Each key on the control panel has different
function, of course you also can get many
new functions by pressing different keys at
the same time or performing different
combinations of keys.
Paper Select Lever
Two positions:
= continuous forms;
= single sheet paper
Paper Feed Knob
Manual feed or vertical positioning of paper
Power Switch
Power printer ON or OFF
Ribbon Cartridge
Install ribbon in the printer
Ribbon Guide
For guiding ribbon installation on print
head
Tractors
For feeding and adjustment of continuous
forms
Power Socket
Connects power cord to the printer
Interface
Connects interface cables from the host
