PC Specialist's Handbook ErgoPro e-, x- and s- Series
First Edition, Release 4 - June 1998 Page 11
Mass memory expansion unit
Differing the main unit from the expansion box
1. Disconnect the power cables and all the other cables connected to the unit.
2. Remove the main unit cover (see page 8)
3. Undo the screw (A) which secures the expansion unit into the chassis of the main unit.
4. Slide the main unit about 40mm(B) toward the front, and lift (C) it slowly straight up as in the picture.
A
B
C
B
A
Picture 15 : Differing the main unit from the expansion box
