ErgoPro e-, x- and s- Series PC Specialist's Handbook
Page 78 First Edition, Release 4 - June 1998
e-, x- and s- series : stucture code
Every ErgoPro has an identification panel located in the system unit. The picture below shows the location of the
identification panel on 2, 4 & 6 slot housings.
This code can be divided into ten parts, indicating that way the exact configuration of the machine. The following
pages are explaining those codes, family by family.
s650/133-16-2000MB
Product :DHLH4C410611
Serial : 74131T8
Product :
1 to 3 : Product family
4. Processor type/Cache
5. DRAM
6. HDD
7. Backup/CD-Rom
12. Brand name, Voltage & Mouse
11. Language code
10. Preinst. Softwares
9. Option board (LAN & Comm. cards)
8. Option board (Controllers & Displays)
DHL H 64 1 04 C 11
2 Slots 4 Slots 6 Slots
