ErgoPro e-, x- and s- Series PC Specialist's Handbook
Page 20 First Edition, Release 4 - June 1998
2-slot PCI/ISA back plane AC41639
Connectors for the shared PCI (1)/ISA slot
ISA-slot connector
System board connector
Note : there are no jumpers on the board
Picture 25: 2 slots PCI/ISA back plane AC41639
4-slot PCI/ISA back plane AC41638
Connectors for the
ISA-slot connectors
System board connector
Note : there are no jumpers on the board
shared PCI (1)/ISA slot
PCI-slot (2) connector
Picture 26 : 4-slot PCI/ISA back plane AC41638
