378 - 37F Parallel port 1 (LPT1), EPP mode
388 - 38B Aztech audio (xs-series)
3B0 - 3DF On-board Local bus HRA10i/ErgoGrafix
3E0 - 3E1 PCMCIA host adapter, when installed.
3F0 - 3F7 Diskette drive controller
3F8 - 3FF Serial port 1 (COM1)
I/O channel addresses 500 to FFFF
Hex range
Device
530 - 537 Aztech audio (xs-series, MS sound system compatibility module)
610 - 61F Aztech audio (xs-series)
678 - 67A Parallel port 2 (LPT 2), ECP mode
778 - 77A Parallel port 1 (LPT 1), ECP mode
46E8 ErgoGrafix 422i
CF8-CFF PCI Host Bridge
A100-A1FF ErgoGrafox 422i, when PCI MACH64 reloc is enabled (RSU)
Timer
The system board has three programmable timers, defined as follows :
Channel
Use
CH 0
System timer
CH 1 DRAM refresh timer
CH 2 Tone generator (Speaker)
Real-time clock (RTC) and CMOS RAM
A real-time clock component provides Real-Time Clock and Calendar functions. The circuit contains 114 bytes of
battery-backed-up CMOS-static RAM memory used for clock functions, and for storing the configuration
information (e.g., the number of diskette drives, the amount of system board memory, etc.).
The CMOS RAM memory is backed up with a non-rechargeable battery that has a considerable lifetime.
However, should the battery begin to fail, the following message (and possibly others) appears on the screen
during the power-on test:
BIOS (27): No battery for CMOS clock/RAM
Press <F1> to continue, <Ins> for set-up mode
If you receive this message check your date and time values in SETUP. It could be that your Time and Date
parameters contain the wrong values, causing the above message to occur. If this is the case, enter the correct
values, save the changes, and this message should disappear.
