ErgoPro e-, x- and s- Series PC Specialist's Handbook
Page 16 First Edition, Release 4 - June 1998
AC XXX
Opti
82C556M
Opti
Opti
82C557M
82C558M
ATI
SMC
320 pin ZIF
Speaker
Remote Boot
ROM Socket
Ethernet module con.
Second Serial port cable conn.
Lithium Battery for RTC & CMOS RAM
Keyb./Mouse
PTC
+3.3V Conn.
Primary IDE
interface conn.
Std FDD interface
conn.
Secondary IDE
interface conn.
KBC
Dallas DS12885
RTC&CMOS RAM
FLASH
Audio Input
ESS688 Audio Chip
CD ROM Conn.
YAMAHA YMF 262
Audio Chip
FAN Conn.
Temperature sensor
selector
Socket type 5
for the CPU
Picture 20 : AC41655/58/59/81/82/87/89 System Board Layout (2)
