Fujitsu ETERNUS AB Series Site Planning Guide

1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
11
Maximum
weight (*2)
(*3)
2.5" type controller shelf 23.5 kg (27.5 kg) 27.4 kg (31.4 kg)
DE224C 2.5" type drive shelf 22.9 kg (26.9 kg) 22.9 kg (26.9 kg)
DE212C 3.5" type drive shelf - 27.6 kg (31.6 kg)
DE460C 60-drive type drive shelf - 106.4 kg (110.4 kg)
Power distribution unit (2U) (*1) (3.0 kg)  2
Power Voltage AC 100 – 120V,
AC 200 – 240V
AC 200 – 240V
Phase Single
Frequency 50 Hz / 60 Hz
Maximum
power
consumption
(*2)
Controller
shelf
2.5" type AC100 – 120V 659 W (665 VA) -
AC200 – 240V 659 W (665 VA) 979 W (979 VA)
Drive shelf DE224C
2.5" type
AC100 – 120V 375 W (379 VA) -
AC200 – 240V 375 W (379 VA) 375 W (379 VA)
DE212C
3.5" type
AC100 – 120V - -
AC200 – 240V - 344 W (344 VA)
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V - 1,460 W (1,466 VA)
Maximum configuration
(*4)
AC100 – 120V 2,159W (2,181 VA) -
AC200 – 240V 2,159W (2,181 VA) 979 W (979 VA)
Maximum
heat
generation
(*2)
Controller
shelf
2.5" type AC100 – 120V 2,371 kJ/h -
AC200 – 240V 2,371 kJ/h 3,525 kJ/h
Drive shelf DE224C
2.5" type
AC100 – 120V 1,350 kJ/h -
AC200 – 240V 1,350 kJ/h 1,350 kJ/h
DE212C
3.5" type
AC100 – 120V - -
AC200 – 240V - 1,237 kJ/h
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V - 5,256 kJ/h
Maximum configuration
(*4)
AC100 – 120V 7,772 kJ/h -
AC200 – 240V 7,772 kJ/h 3,525 kJ/h
Maximum
amount of
exhaust air
Controller shelf - -
Drive shelf - -
Item ETERNUS AB5100 ETERNUS AB6100
