Fujitsu ETERNUS AB Series Site Planning Guide

Site Planning Guide
8
1. ETERNUS AB/HB Installation
This chapter provides the installation specification of the ETERNUS AB/HB.
Installation Specifications
• ETERNUS AB series All-Flash Arrays
- "
ETERNUS AB2100/AB3100" (page 8)
- "ETERNUS AB5100/AB6100" (page 10)
• ETERNUS HB series Hybrid Arrays
- "
ETERNUS HB1100/HB1200" (page 13)
- "ETERNUS HB2100/HB2200" (page 15)
- "ETERNUS HB2300" (page 18)
- "ETERNUS HB5100/HB5200" (page 20)
ETERNUS AB2100/AB3100
Each installation specification is shown below.
• Installation specifications: Table 1
• Sound level of the drive shelf: Table 2
• Efficiency and the power factor of the power supply unit: Table 3
Table 1 Installation Specifications (ETERNUS AB2100/AB3100)
Item ETERNUS AB2100 ETERNUS AB3100
Dimensions
(W  D  H)
2.5" type controller shelf 480  483  85 mm
(2U)
483  543  87 mm
(2U)
DE224C 2.5" type drive shelf 480  484  85 mm
(2U)
480  484  85 mm
(2U)
DE212C 3.5" type drive shelf - 480  505  87 mm
(2U)
DE460C 60-drive type drive shelf - 486  922  176 mm
(4U)
Power distribution unit
(AC24A/200V, 16 outlets) (2U) (*1)
(485  123  44 mm)  2
Power distribution unit
(AC24A/250V, six outlets) (2U) (*1)
-(482  73  44 mm)
 2
Maximum
weight (*2)
(*3)
2.5" type controller shelf 23.6 kg (27.6 kg) 27.4 kg (31.4 kg)
DE224C 2.5" type drive shelf 22.9 kg (26.9 kg) 22.9 kg (26.9 kg)
DE212C 3.5" type drive shelf - 27.6 kg (31.6 kg)
DE460C 60-drive type drive shelf - 106.4 kg (110.4 kg)
Power distribution unit
(AC24A/200V, 16 outlets) (2U) (*1)
(3.0 kg)  2
Power distribution unit
(AC24A/250V, six outlets) (2U) (*1)
-(3.7 kg)  2
Power Voltage AC100 – 120 V, AC200 – 240 V
Phase Single
Frequency 50 Hz / 60 Hz
