Fujitsu ETERNUS AB Series Site Planning Guide

1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
18
*1: Indicates the rated load against the rated output of the PSU.
ETERNUS HB2300
Each installation specification is shown below.
• Installation specifications: Table 13
• Sound level of the drive shelf: Table 14
• Efficiency and the power factor of the power supply unit: Table 15
Table 13 Installation Specifications (ETERNUS HB2300)
Item ETERNUS HB2300
Dimensions
(W  D  H)
3.5" type controller shelf 486  922  176 mm (4U)
DE212C 3.5" type drive shelf 480  505  87 mm (2U)
DE224C 2.5" type drive shelf 480  484  85 mm (2U)
DE460C 60-drive type drive shelf 486  922  176 mm (4U)
Power distribution unit
(AC24A/200V, 16 outlets) (2U) (*1)
(485  123  44 mm)  2
Power distribution unit
(AC24A/200V, six outlets) (2U) (*1)
(482  73  44 mm)  2
Maximum
weight (*2)
(*3)
3.5" type controller shelf 108.1 kg (112.1 kg)
DE212C 3.5" type drive shelf 27.6 kg (31.6 kg)
DE224C 2.5" type drive shelf 22.9 kg (26.9 kg)
DE460C 60-drive type drive shelf 106.4 kg (110.4 kg)
Power distribution unit
(AC24A/200V, 16 outlets) (2U) (*1)
(3.0 kg)  2
Power distribution unit
(AC24A/200V, six outlets) (2U) (*1)
(3.7 kg)  2
Power Voltage AC 200 – 240V
Phase Single
Frequency 50 Hz / 60 Hz
Maximum
power
consumption
(*2)
Controller
shelf
3.5" type AC100 – 120V -
AC200 – 240V 1,537 W (1,543 VA)
Drive shelf DE212C
3.5" type
AC100 – 120V -
AC200 – 240V 344 W (344 VA)
DE224C
2.5" type
AC100 – 120V -
AC200 – 240V 452 W (450 VA)
DE460C
60-drive
type
AC100 – 120V -
AC200 – 240V 1,460 W (1,466 VA)
Maximum configuration
(*4)
AC100 – 120V -
AC200 – 240V 4,801 W (4,819 VA)
