1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
13
ETERNUS HB1100/HB1200
Each installation specification is shown below.
• Installation specifications: Table 7
• Sound level of the drive shelf: Table 8
• Efficiency and the power factor of the power supply unit: Table 9
Table 7 Installation Specifications (ETERNUS HB1100/HB1200)
Item ETERNUS HB1100 ETERNUS HB1200
Dimensions
(W D H)
3.5" type controller shelf 480 505 87 mm
(2U)
-
2.5" type controller shelf - 480 483 85 mm
(2U)
DE212C 3.5" type drive shelf 480 505 87 mm
(2U)
-
DE224C 2.5" type drive shelf - 480 484 85 mm
(2U)
Power distribution unit (2U) (*1) (485 123 44 mm) 2
Maximum
weight (*2)
(*3)
3.5" type controller shelf 29.3 kg (33.3 kg) -
2.5" type controller shelf - 24.6 kg (28.6 kg)
DE212C 3.5" type drive shelf 27.6 kg (31.6 kg) -
DE224C 2.5" type drive shelf - 22.9 kg (26.9 kg)
Power distribution unit (2U) (*1) (3.0 kg) 2
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50 Hz / 60 Hz
Maximum
power
consumption
(*2)
Controller
shelf
3.5" type AC100 – 120V 565 W (568 VA) -
AC200 – 240V 565 W (568 VA) -
2.5" type AC100 – 120V - 674 W (674 VA)
AC200 – 240V - 674 W (674 VA)
Drive shelf DE212C
3.5" type
AC100 – 120V 344 W (344 VA) -
AC200 – 240V 344 W (344 VA) -
DE224C
2.5" type
AC100 – 120V - 452 W (450 VA)
AC200 – 240V - 452 W (450 VA)
Maximum configuration
(*4)
AC100 – 120V 909 W (912 VA) 1,126 W (1,124 VA)
AC200 – 240V 909 W (912 VA) 1,126 W (1,124 VA)
Maximum
heat
generation
(*2)
Controller
shelf
3.5" type AC100 – 120V 2,035 kJ/h -
AC200 – 240V 2,035 kJ/h -
2.5" type AC100 – 120V - 2,425 kJ/h
AC200 – 240V - 2,425 kJ/h
Drive shelf DE212C
3.5" type
AC100 – 120V 1,237 kJ/h -
AC200 – 240V 1,237 kJ/h -
DE224C
2.5" type
AC100 – 120V - 1,627 kJ/h
AC200 – 240V - 1,627 kJ/h
Maximum configuration
(*4)
AC100 – 120V 3,273 kJ/h 4,052 kJ/h
AC200 – 240V 3,273 kJ/h 4,052 kJ/h
