Page #22 background imageLoading...
Page #22 background image
1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
22
*1: A power distribution unit is composed of two 1U power distribution units.
*2: These values are for each shelf when 24 drives are installed in a 2.5" type shelf, 12 drives are installed in a
3.5" type shelf, or 60 drives are installed in a 60-drive shelf.
*3: The value in the parentheses for the controller shelf and drive shelves includes the mass of the rack rail kit.
*4: These values are for the maximum load when all the available options are installed in an ETERNUS AB/HB.
*5: The operating test was performed in environments compatible with the Operating Condition Class A3 of
the EU eco-design directive (ErP Directive 2009/125/EC).
*6: For details about the sound level of the drive shelf, refer to "Table 17
Sound Level of the Drive Shelf"
(page 22).
Table 17 Sound Level of the Drive Shelf
Table 18 Efficiency and Power Factor of the Power Supply Unit
*1: Indicates the rated load against the rated output of the PSU.
19-inch Racks
The following table shows the installation specifications of the 19-inch racks.
Table 19 19-inch Rack Installation Specifications
Noise
emission (*6)
Sound pressure level 51 dBA 72 dBA
Sound power level 6.7 B 7.2 B
DE224C DE460C
Sound pressure level 51 dBA 72 dBA
Sound power level 6.7 B 7.2 B
Component name
80PLUS®
Efficiency Power factor
Output
Shelf 20 % (*1) 50 % (*1) 100 % (*1) 50 % (*1)
ETERNUS HB5100 Platinum 91.8 % 94.2 % 92.7 % 0.980 Multiple output
ETERNUS HB5200 91.9 % 94.4 % 93.4 % 0.990
DE224C drive shelf 91.8 % 94.2 % 92.7 % 0.980
DE460C drive shelf 91.9 % 94.4 % 93.4 % 0.990
Item ETERNUS HB5100 ETERNUS HB5200
Item
Specification
Base rack Expansion rack
Dimensions (W D H) 700 1,050 2,000 mm
700 1,272 2,000 mm (including anti-tipping stabilizer)
Maximum weight 129 kg 103 kg
Service area Refer to Figure 14
under "Installation Area" (page 34).
Number of units 42U
