1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
21
Maximum
power
consumption
(*2)
Controller
shelf
3.5" type AC100 – 120V - -
AC200 – 240V - 1,777 W (1,793 VA)
2.5" type AC100 – 120V 694 W (701 VA) -
AC200 – 240V 694 W (701 VA) -
Drive shelf DE224C
2.5" type
AC100 – 120V 423 W (426 VA) -
AC200 – 240V 423 W (426 VA) 423 W (426 VA)
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V 1,486 W (1,501 VA) 1,486 W (1,501 VA)
Maximum configuration
(*4)
AC100 – 120V 3,652 W (3,683 VA) -
AC200 – 240V 11,093 W (11,208 VA) 12,176 W (12,300 VA)
Maximum
heat
generation
(*2)
Controller
shelf
3.5" type AC100 – 120V - -
AC200 – 240V - 6,397 kJ/h
2.5" type AC100 – 120V 2,499 kJ/h -
AC200 – 240V 2,499 kJ/h -
Drive shelf DE224C
2.5" type
AC100 – 120V 1,521 kJ/h -
AC200 – 240V 1,521 kJ/h 1,521 kJ/h
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V 5,348 kJ/h 5,348 kJ/h
Maximum configuration
(*4)
AC100 – 120V 13,148 kJ/h -
AC200 – 240V 39,937 kJ/h 43,835 kJ/h
Maximum
amount of
exhaust air
Controller shelf - -
Drive shelf 2.5" type / 3.5" type - -
60-drive type - -
Environmental
conditions
Temperature Operating (*5) 5 – 40 °C
Not operating -40 – 70 °C
During shipment -40 – 70 °C
Temperature gradient 15 °C/Hr or less
Humidity Operating (*5) 8 – 85 %RH
Not operating 5 – 95 %RH 10 – 95 %RH
During shipment 10 – 95 %RH
Humidity gradient 30 %/day or less
Maximum wet bulb temperature 29 °C
Altitude above sea level 0 – 3,048 m -30.5 – 3,048 m
Airborne dust
0.15 mg/m
3
or less
Gas concentration tolerance level Cl
2
: 6.8 ppb or less, H
2
S: 7.1 ppb or less,
SO
2
: 37 ppb or less, NH
3
: 423.5 ppb or less,
NO
2
: 52.3 ppb or less, O
3
: 5 ppb or less,
HCl: 6.6 ppb or less, HF: 3.6 ppb or less
Oil vapor
0.2 mg/m
3
or less
Seawater (salt corrosion) If the ETERNUS AB/HB is installed on the
ocean or premises within 0.5 km from the
coast, necessary measures must be taken
to prevent salt corrosion.
Item ETERNUS HB5100 ETERNUS HB5200
