2. Rack Installation Specifications

Rack Installation Requirements

Site Planning Guide

Cable Connection (Mini SAS HD Cable)

Mini SAS HD cables are used to connect between shelves in the ETERNUS AB/HB. Four (2 m) are

provided with each drive shelf.

For extended connections, 5 m cables are available. To connect between shelves across racks, use 5

m cables.

Figure 27 Cable Connection (Mini SAS HD Cable)

The field engineer (FE) will perform the cable connection work.

Controller shelf

Drive shelf
