Fujitsu ETERNUS AB Series Site Planning Guide

1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
15
Table 9 Efficiency and Power Factor of the Power Supply Unit
*1: Indicates the rated load against the rated output of the PSU.
ETERNUS HB2100/HB2200
Each installation specification is shown below.
• Installation specifications: Table 10
• Sound level of the drive shelf: Table 11
• Efficiency and the power factor of the power supply unit: Table 12
Table 10 Installation Specifications (ETERNUS HB2100/HB2200)
Component name
80PLUS®
Efficiency Power factor
Output
Shelf 20 % (*1) 50 % (*1) 100 % (*1) 50 % (*1)
ETERNUS HB1100 Platinum 91.8 % 94.2 % 92.7 % 0.980 Multiple output
ETERNUS HB1200 91.8 % 94.2 % 92.7 % 0.980
DE212C drive shelf 91.8 % 94.2 % 92.7 % 0.980
DE224C drive shelf 91.8 % 94.2 % 92.7 % 0.980
Item ETERNUS HB2100 ETERNUS HB2200
Dimensions
(W  D  H)
3.5" type controller shelf 480  505  87 mm
(2U)
-
2.5" type controller shelf - 480  483  85 mm
(2U)
DE212C 3.5" type drive shelf 480  505  87 mm (2U)
DE224C 2.5" type drive shelf 480  484  85 mm (2U)
DE460C 60-drive type drive shelf 486  922  176 mm (4U)
Power distribution unit
(AC24A/200V, 16 outlets) (2U) (*1)
(485  123  44 mm)  2
Power distribution unit
(AC24A/250V, six outlets) (2U) (*1)
(482  73  44 mm)  2
Maximum
weight (*2)
(*3)
3.5" type controller shelf 29.3 kg (33.3 kg) -
2.5" type controller shelf - 24.6 kg (28.6 kg)
DE212C 3.5" type drive shelf 27.6 kg (31.6 kg) 27.6 kg (31.6 kg)
DE224C 2.5" type drive shelf 22.9 kg (26.9 kg) 22.9 kg (26.9 kg)
DE460C 60-drive type drive shelf 106.4 kg (110.4 kg) 106.4 kg (110.4 kg)
Power distribution unit
(AC24A/200V, 16 outlets) (*1)
(3.0 kg)  2
Power distribution unit
(AC24A/250V, six outlets) (*1)
(3.7 kg)  2
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50 Hz / 60 Hz
