Fujitsu ETERNUS AB Series Site Planning Guide

1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
16
Maximum
power
consumption
(*2)
Controller
shelf
3.5" type AC100 – 120V 565 W (568 VA) -
AC200 – 240V 565 W (568 VA) -
2.5" type AC100 – 120V - 674 W (674 VA)
AC200 – 240V - 674 W (674 VA)
Drive shelf DE212C
3.5" type
AC100 – 120V 344 W (344 VA) 344 W (344 VA)
AC200 – 240V 344 W (344 VA) 344 W (344 VA)
DE224C
2.5" type
AC100 – 120V 452 W (450 VA) 452 W (450 VA)
AC200 – 240V 452 W (450 VA) 452 W (450 VA)
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V 1,460 W (1,466 VA) 1,460 W (1,466 VA)
Maximum configuration
(*4)
AC100 – 120V 1,921 W (1,918 VA) 2,029 W (2,024 VA)
AC200 – 240V 4,945 W (4,966 VA) 4,046 W (4,056 VA)
Maximum
heat
generation
(*2)
Controller
shelf
3.5" type AC100 – 120V 2,035 kJ/h -
AC200 – 240V 2,035 kJ/h -
2.5" type AC100 – 120V - 2,425 kJ/h
AC200 – 240V - 2,425 kJ/h
Drive shelf DE212C
3.5" type
AC100 – 120V 1,237 kJ/h 1,237 kJ/h
AC200 – 240V 1,237 kJ/h 1,237 kJ/h
DE224C
2.5" type
AC100 – 120V 1,627 kJ/h 1,627 kJ/h
AC200 – 240V 1,627 kJ/h 1,627 kJ/h
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V 5,256 kJ/h 5,256 kJ/h
Maximum configuration
(*4)
AC100 – 120V 6,916 kJ/h 7,305 kJ/h
AC200 – 240V 17,803 kJ/h 14,564 kJ/h
Maximum
amount of
exhaust air
Controller shelf - -
Drive shelf 2.5" type / 3.5" type - -
60-drive type - -
Item ETERNUS HB2100 ETERNUS HB2200
