2. Rack Installation Specifications
Rack Installation Requirements
Site Planning Guide
51
Cable Connection
Cable Connection (Power)
This section explains the requirements for connecting a power distribution unit with the ETERNUS
AB/HB.
● Power Distribution Units (2U, 16 Outlets, 24A)
• For each power distribution unit, the total current capacity of the current consumption value of
the power cords that connect from outlets OUT1 to OUT8 must be 24A or less.
• For each power distribution unit, the total current capacity of the current consumption value of
the power cords that connect from outlets OUT1 to OUT4 and total current capacity of the cur-
rent consumption value of the power cords that connect from outlets OUT5 to OUT8 must be
12A or less.
• Connect a new shelf to OUT5 if the total current capacity of the current consumption value of
the power cords that connect from outlets OUT1 to OUT4 exceeds 12A.
Connect a new shelf to the next power distribution unit if the total current capacity of the cur-
rent consumption value of the power cords that connect from outlets OUT5 to OUT8 exceeds
12A.
● Power Distribution Units (2U, 6 Outlets, 24A)
• For each power distribution unit, the total current capacity of the current consumption value of
the power cords that connect from outlets OUT1 to OUT3 must be 24A or less.
