Fujitsu ETERNUS AB Series Site Planning Guide

1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
17
*1: A power distribution unit is composed of two 1U power distribution units.
*2: These values are for each shelf when 24 drives are installed in a 2.5" type shelf, 12 drives are installed in a
3.5" type shelf, or 60 drives are installed in a 60-drive shelf.
*3: The value in the parentheses for the controller shelf and drive shelves includes the mass of the rack rail kit.
*4: These values are for the maximum load when all the available options are installed in a 2.5" type or 3.5"
type ETERNUS AB/HB.
*5: The operating test was performed in environments compatible with the Operating Condition Class A4 of
the EU eco-design directive (ErP Directive 2009/125/EC).
*6: The operating test was performed in environments compatible with the Operating Condition Class A3 of
the EU eco-design directive (ErP Directive 2009/125/EC).
*7: For details about the sound level of the drive shelf, refer to "Table 11
Sound Level of the Drive Shelf" (page
17).
Table 11 Sound Level of the Drive Shelf
Table 12 Efficiency and Power Factor of the Power Supply Unit
Environmental
conditions
Temperature Operating 5 – 45 °C (*5) 5 – 40 °C (*6)
Not operating -40 – 70 °C
During shipment -40 – 70 °C
Temperature gradient 15 °C/Hr or less
Humidity Operating 8 – 90 %RH (*5) 8 – 85 %RH (*6)
Not operating 5 – 95 %RH
During shipment 10 – 95 %RH
Humidity gradient 30 %/day or less
Maximum wet bulb temperature 29 °C
Altitude above sea level 0 – 3,048 m
Airborne dust
0.15 mg/m
3
or less
Gas concentration tolerance level Cl
2
: 6.8 ppb or less, H
2
S: 7.1 ppb or less,
SO
2
: 37 ppb or less, NH
3
: 423.5 ppb or less,
NO
2
: 52.3 ppb or less, O
3
: 5 ppb or less,
HCl: 6.6 ppb or less, HF: 3.6 ppb or less
Oil vapor
0.2 mg/m
3
or less
Seawater (salt corrosion) If the ETERNUS AB/HB is installed on the
ocean or premises within 0.5 km from the
coast, necessary measures must be taken
to prevent salt corrosion.
Noise
emission (*7)
Sound pressure level 64 dBA
Sound power level 6.4 B
DE212C DE224C DE460C
Sound pressure level 64 dBA 51 dBA 72 dBA
Sound power level 6.4 B 6.7 B 7.2 B
Component name
80PLUS®
Efficiency Power factor
Output
Shelf 20 % (*1) 50 % (*1) 100 % (*1) 50 % (*1)
ETERNUS HB2100 Platinum 91.8 % 94.2 % 92.7 % 0.980 Multiple output
ETERNUS HB2200 91.8 % 94.2 % 92.7 % 0.980
DE212C drive shelf 91.8 % 94.2 % 92.7 % 0.980
DE224C drive shelf 91.8 % 94.2 % 92.7 % 0.980
DE460C drive shelf 91.9 % 94.4 % 93.4 % 0.990
Item ETERNUS HB2100 ETERNUS HB2200
