Fujitsu ETERNUS AB Series Site Planning Guide

1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
10
*1: A 2U power distribution unit is composed of two 1U power distribution units.
*2: These values are for each shelf when 24 drives are installed.
*3: The value in the parentheses for the controller shelf and drive shelves includes the mass of the rack rail kit.
*4: These values are for the maximum load when all the available options are installed in an ETERNUS AB/HB.
*5: The operating test was performed in environments compatible with the Operating Condition Class A2 of
the EU eco-design directive (ErP Directive 2009/125/EC).
*6: The operating test was performed in environments compatible with the Operating Condition Class A3 of
the EU eco-design directive (ErP Directive 2009/125/EC).
*7: For details about the sound level of the drive shelf, refer to "Table 2
Sound Level of the Drive Shelf" (page
10).
Table 2 Sound Level of the Drive Shelf
Table 3 Efficiency and Power Factor of the Power Supply Unit
*1: Indicates the rated load against the rated output of the PSU.
ETERNUS AB5100/AB6100
Each installation specification is shown below.
• Installation specifications: Table 4
• Sound level of the drive shelf: Table 5
• Efficiency and the power factor of the power supply unit: Table 6
Table 4 Installation Specifications (ETERNUS AB5100/AB6100)
DE224C
Sound pressure level 51 dBA
Sound power level 6.7 B
Component name
80PLUS®
Efficiency Power factor
Output
Shelf 20 % (*1) 50 % (*1) 100 % (*1) 50 % (*1)
ETERNUS AB2100 Platinum 91.8 % 94.2 % 92.7 % 0.980 Multiple output
ETERNUS AB3100 93.5 % 94.2 % 91.4 % 1.000 Single output
ETERNUS AB3100 Titanium 94.7 % 96.1 % 94.5 % 1.000 Single output
DE224C drive shelf Platinum 91.8 % 94.2 % 92.7 % 0.980 Multiple output
DE212C drive shelf 91.8 % 94.2 % 92.7 % 0.980
DE460C drive shelf 91.9 % 94.4 % 93.4 % 0.990
Item ETERNUS AB5100 ETERNUS AB6100
Dimensions
(W  D  H)
2.5" type controller shelf 480  483  85 mm
(2U)
483  543  87 mm
(2U)
DE224C 2.5" type drive shelf 480  484  85 mm
(2U)
480  484  85 mm
(2U)
DE212C 3.5" type drive shelf - 480  505  87 mm
(2U)
DE460C 60-drive type drive shelf - 486  922  176 mm
(4U)
Power distribution unit (2U) (*1) (485  123  44 mm)  2
