Fujitsu ETERNUS AB Series Site Planning Guide

1. ETERNUS AB/HB Installation
Installation Specifications
Site Planning Guide
9
Maximum
power
consumption
(*2)
Controller
shelf
2.5" type AC100 – 120V 659 W (665 VA) -
AC200 – 240V 659 W (665 VA) 953 W (964 VA)
Drive shelf DE224C
2.5" type
AC100 – 120V 375 W (379 VA) -
AC200 – 240V 375 W (379 VA) 375 W (379 VA)
DE212C
3.5" type
AC100 – 120V - -
AC200 – 240V - 344 W (344 VA)
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V - 1,460 W (1,466 VA)
Maximum configuration
(*4)
AC100 – 120V 1,784 W (1,802 VA) -
AC200 – 240V 1,784 W (1,802 VA) 6,793 W (6,828 VA)
Maximum
heat
generation
(*2)
Controller
shelf
2.5" type AC100 – 120V 2,371 kJ/h -
AC200 – 240V 2,371 kJ/h 3,431 kJ/h
Drive shelf DE224C
2.5" type
AC100 – 120V 1,350 kJ/h -
AC200 – 240V 1,350 kJ/h 1,350 kJ/h
DE212C
3.5" type
AC100 – 120V - -
AC200 – 240V - 1,237 kJ/h
DE460C
60-drive
type
AC100 – 120V - -
AC200 – 240V - 5,256 kJ/h
Maximum configuration
(*4)
AC100 – 120V 6,422 kJ/h -
AC200 – 240V 6,422 kJ/h 24,455 kJ/h
Maximum
amount of
exhaust air
Controller shelf -
Drive shelf -
Environmental
conditions
Temperature Operating 10 – 35 °C (*5) 10 – 35 °C (*6)
Not operating -40 – 70 °C
During shipment -40 – 70 °C
Temperature gradient 15 °C/Hr or less
Humidity Operating 8 – 85 %RH (*5) 8 – 85 %RH (*6)
Not operating 5 – 95 %RH
During shipment 10 – 95 %RH
Humidity gradient 30 %/day or less
Maximum wet bulb temperature 29 °C
Altitude above sea level 0 – 3,048 m
Airborne dust
0.15 mg/m
3
or less
Gas concentration tolerance level Cl
2
: 6.8 ppb or less, H
2
S: 7.1 ppb or less,
SO
2
: 37 ppb or less, NH
3
: 423.5 ppb or less,
NO
2
: 52.3 ppb or less, O
3
: 5 ppb or less,
HCl: 6.6 ppb or less, HF: 3.6 ppb or less
Oil vapor
0.2 mg/m
3
or less
Seawater (salt corrosion) If the ETERNUS AB/HB is installed on the
ocean or premises within 0.5 km from the
coast, necessary measures must be taken
to prevent salt corrosion.
Noise
emission (*7)
Sound pressure level 67 dBA 69.1 dBA
Sound power level 6.7 B 7.2 B
Item ETERNUS AB2100 ETERNUS AB3100
