Fujitsu ETERNUS AB Series Site Planning Guide

2. Rack Installation Specifications
Installable Racks
Site Planning Guide
55
*1: For the ETERNUS HB2300, ETERNUS HB5200, and DE460C, the recommended depth of the rack
space is equal to the depth of the shelf body (922 mm) + 60 mm or more because the cable connec-
tion interface has depth of 40 mm from the rear surface of the shelf.
■ Installation Requirements
When determining service areas, refer to the manual of the rack that is to be used.
Be sure to perform the installation according to the requirements described in "
Installation Specifi-
cations" (page 8) and "Installation Environment" (page 36).
(3) Rack space
(Space between the fixed part of the ETERNUS
AB/HB on the front side and the rear of the rack)
The depth of the shelf body (*1) + 100 mm
or more (recommended for the extra
cable length)
(4) Rack mount kit installation area 483 mm or more (recommended)
Specification Condition
