ETERNUS AF650 S3
Figure 9 Front View of a Controller Enclosure (for the ETERNUS AF650 S3, with a Front Cover)
1
2
1 Operation panel (refer to "
■ Operation Panel" (page 71))
2 Front cover
Figure 10 Front View of a Controller Enclosure (for the ETERNUS AF650 S3, without a Front Cover)
1
2 2
BBU#1BBU#0
Slot#0
Slot#1
Slot#2
Slot#3
Slot#4
Slot#5
Slot#6
Slot#7
Slot#8
Slot#9
Slot#10
Slot#11
Slot#12
Slot#13
Slot#14
Slot#15
Slot#16
Slot#17
Slot#18
Slot#19
Slot#20
Slot#21
Slot#22
Slot#23
1 2.5" drive (refer to "■ Drives" (page
73))
2 Battery (BBU#0, BBU#1) (refer to "■ Batteries" (page 81))
A. Component Names
Controller Enclosure
68 Operation Guide (Basic)
