Parameter
Setting value
(for direct connection)
Setting value
(for switch connec-
tion)
lpfcX
(Instance name)
Remarks
xmt-que-size 256 256 — —
lpfcX-scan-down 1 0 Yes An instance name is
specified for each in-
stance.
linkdown-tmo 30 30 — —
nodev-holdio 0 0 — —
nodev-tmo 40 40 — —
delay-rsp-err 0 0 — —
num-iocbs 256 256 — —
num-bufs 128 128 — —
lpfcX-topology 4 2 Yes An instance name is
specified for each in-
stance.
ip-class 3 3 — —
fcp-class 3 3 — —
use-adisc 0 0 — —
extra-io-tmo 0 0 — —
post-ip-buf 128 128 — —
dqfull-throttle-up-time 1 1 — —
dqfull-throttle-up-inc 1 1 — —
ack0 0 0 — —
cr-delay 0 0 — —
cr-count 1 1 — —
discovery-threads 1 1 — —
lpfcX-link-speed 2 or 4
(*2)
1, 2, or 4
(*2)
Yes An instance name is
specified for each in-
stance.
fdmi-on 0 0 — —
*1: For switch connection, set as follows:
fcp-bind-WWPN="<Storage WWPN>:<HBA instance name>t<SCSI ID>",.....
Check the target binding table for the fcp-bind-WWPN setting.
Channel Adapter name
SCSI T-ID
RAID-WWN
Instance name
CM0CA0Port0
CM1CA0Port0
16
16
203000e000cb0001
lpfc0
lpfc1
fcp-bind-WWPN="202000e000cb0001:lpfc0t16","203000e000cb0001:lpfc1t
*2: "lpfcX-link-speed" setting value
Fibre Channel card trans-
fer rate
Switch connection
(Fibre Channel switch transfer rate)
Direct connec-
tion
8Gbit/s 4Gbit/s 2Gbit/s 1Gbit/s
4Gbit/s 4 4 2 1 4
