4.4 Setting Up the Server to Recognize the Logical Units
Set the server to recognize the ETERNUS DX/AF storage systems' logical units.
Execute the following commands to check the path of the ETERNUS DX/AF to be connected.
1 Execute the following command to confirm that the server can access the logical units.
# cfgadm -al
# cfgadm -al
Ap_Id Type Receptacle Occupant Condition
c2 fc-fabric connected configured unknown
c2::500000e0d0400006 disk connected configured unknown
c3 fc-fabric connected configured unknown
c3::500000e0d0400086 disk connected configured unknown
Underlined portion indicates that the ETERNUS DX/AF CA (WWN:500000e0d0400086) are connected to
the Fibre Channel card port with controller number "c3".
2 Use the following command to confirm that the storage system and all the logical units have been cor-
rectly recognized.
# format
# format
Searching for disks...done
AVAILABLE DISK SELECTIONS:
0. c0t0d0 <SUN146G cyl 14087 alt 2 hd 24 sec 848>
/pci@780/pci@0/pci@9/scsi@0/sd@0,0
1. c2t500000E0D0400006d0 <FUJITSU-ETERNUS_DXL-0000 cyl 379 alt 2 hd 64 sec 256>
/pci@7c0/pci@0/pci@8/bfa@0/fp@0,0/ssd@w500000e0d0400006,0
2. c2t500000E0D0400006d1 <FUJITSU-ETERNUS_DXL-0000 cyl 379 alt 2 hd 64 sec 256>
/pci@7c0/pci@0/pci@8/bfa@0/fp@0,0/ssd@w500000e0d0400006,1
3.
c3t500000E0D0400086d0 <FUJITSU-ETERNUS_DXL-0000 cyl 379 alt 2 hd 64 sec 256>
/pci@7c0/pci@0/pci@8/bfa@0,1/fp@0,0/ssd@w500000e0d0400086,0
4.
c3t500000E0D0400086d1 <FUJITSU-ETERNUS_DXL-0000 cyl 379 alt 2 hd 64 sec 256>
/pci@7c0/pci@0/pci@8/bfa@0,1/fp@0,0/ssd@w500000e0d0400086,1
The underlined portion indicates that the ETERNUS DX/AF target ID=500000E0D0400086, lun=0 and 1
are connected to physical path /pci@7c0/pci@0/pci@8/bfa@0,1 and c3t500000E0D0400086d0 and
c3t500000E0D0400086d1 are assigned to each of these LUNs.
Chapter 4
Operations When Using Brocade Fibre Channel Cards
4.4 Setting Up the Server to Recognize the Logical Units
81
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0
