2.9 Correcting skewed Documents
fi-5530C Image Scanner Operator’s Guide 51
SCANNING VARIOUS TYPES OF DOCUMENTS
2
4. Click the [OK] button.
The display returns to the scanninig operation [TWAIN Driver] dialogbox.
Then, scan the documents by the dialogbox.
HINT
With [Priority] slider control, you can change accuracy of Automatic
Page Size Detection. Move the slider to the right when improving the
detection accuracy. (Note that higher accuracy setting requires much
more processing time and scanning speed becomes slower.)
ATTENTION
When using either of the following documents, the Automatic page size
detection may not function correctly.
1. Paper of weight 52g/m
2
or less.
2. Not rectangular documents.
3. Documents which their edges are filled with black margins.
To Next Page
