7.2 Installation Specifications
Item Specification
Dimensions
(Without ADF paper chute and Stacker)
Depth Width Height
225 mm
(8.9 in)
399 mm
(15.7 in)
193 mm
(7.6 in)
Installation Space
(D x W x H)
800 x 500 x 500 mm
(31.5 x 19.7 x 19.7 in)
Weight 8.5 kg (18.7 lb)
Input power Voltage 100 to 120 VAC ±10% 220 to 240 VAC ±10%
Phases Single-phase
Frequency 50 / 60 ± 3Hz
Power consumption 57 W or less
Ambient
condition
Device status Operating Not operating
Temperature 5 to 35 °C
(41 to 95 °F)
-20 to 60 °C
(-4 to 140 °F)
Humidity 20 to 80 % 8 to 95 %
Heat capacity 49 kcal / H or less
Shipping Weight 12 kg (33 lb)
ATTENTION
Installation Space is the reference value of an installation space required
to read A3 documents.
ATTENTION
Refer to Chapter 4 "REPLACING CONSUMABLES" (page 61) for details
on the scanned number of sheets for current consumable.
