4.2 Replacing the Pad ASSY
1. Remove all documents from the ADF paper chute.
2. Open the ADF by pushing down the ADF button.
3. Remove the Pad ASSY.
Pinch the Pad ASSY and slide it to the direction of the arrow and remove it.
CAUTION
Be careful, the ADF cover may close and pinch your
fingers.
ADF button
