70
4.3 Replacing the Pick Roller
1. Remove all documents from the ADF paper chute.
2. Remove the ADF paper chute.
3. Open the ADF by pushing down the ADF button.
CAUTION
Be careful, the ADF cover may close and pinch your
fingers.
ADF paper chute
ADF button
