Fujitsu fi-5530C - Document Scanner

4.3 Replacing the Pick Roller
fi-5530C Image Scanner Operator’s Guide 75
REPLACING CONSUMABLES
4
8. Push in the center of the ADF to close it until the ADF button is locked.
9. Attach the ADF paper chute to the scanner.
Press the center
of the ADF
ADF Paper Chute
