Adjusting the Start Position for Scanning
[Offset/Vertical magnification Adjustment]
When the output position of the scanned image is not correct
or the image appears shortened/elongated (vertically), use the
following procedure to adjust the offset and the vertical
magnification for correction.
1 Start up the Software Operation Panel.
Refer to "9.1 Starting Up the Software Operation Panel" (page 125).
2 From the listing on the left, select [Device Setting] and
click the [Offset] button.
9.5 Settings Related to Scanning
Normally, you should not have to make any adjustments as the
factory default settings are configured at appropriate values.
