Fujitsu PRIMERGY RX300 S6 - Further Options Installation; Installing T-Handles

RX300 S6 Options Guide 105
9 Further options
V CAUTION!
Please note the safety instructions in chapter "Safety instructions" on
page 19
9.1 T-handles
Figure 83: Installing the T-handle
Ê Remove the black pads (1) out of the square hole in the front cover.
Ê Insert the handle from the front side (2).
Ê Tighten the handle with the screw (3) (torque value of 1.8 Nm).
Ê Install the second handle in the same way as the first.
/
